7.1 Surround Sound Bar with Wireless Subwoofer

Innovative. Exclusive. Unprecedented.


Meet SHOCKWAFE, Nakamichi's reference series sound bar in a return to its original, high-end heritage. Pioneered with revolutionary Surround Effects Tweeters, SHOCKWAFE's 7.1 Channel sound bar offers the widest, life-like surround sound for an unparalleled theater experience.

With over 60 years of audio expertise, we're literally making waves.

shockwafe life like surround
shockwafe room filling sound
shockwafe unparalleled design

SHOCKWAFE uses Dolby Audio and DTS Digital Surround technology to bring true dimension to your audio. Our exclusive Effects Tweeters immerse your theater with ultra-wide 7.1 Ch surround sound.

Enjoy true cinema sound in your own home with 10 speaker drivers + an 8" wireless subwoofer capable of hitting up to 104dB sound pressure level and 35Hz deep bass, respectively.

Screen Shot 2015-12-18 at 1.44.07 AM.png

Every aspect of SHOCKWAFE was designed with a purpose, from its sleek metallic accents to the backlit LCD learning remote.

shockwafe technology

SHOCKWAFE'S surround is in a class of its own.

Screen Shot 2016-01-03 at 4.20.45 AM.png

Surround effects tweeters

Two exclusive Surround Effects tweeters enhance clarity and acoustic wideness, producing the most realistic and immersive sound stage to your home theater environment.

Unprecedented Surround Realism

Surround Effects tweeters unlock next level surround performance by reflecting sound off walls, ceiling and floor. Radiating life-like sound directly to the audience.

Screen Shot 2016-01-03 at 4.34.21 AM.png

exceptional audio engineering

Distinguished premium construction featuring 5 individually sealed sound chambers to achieve a discrete audio configuration for each channel, dramatically expanding the immersiveness of your favorite movies and music.

Experience true happiness at home with your loved ones with SHOCKWAFE's life-like surround.

You don't know what you're getting into.

With 11 precisely tuned speaker drivers including a 8" wireless subwoofer and rear satellite speakers, SHOCKWAFE knows no boundaries with its immense power.

This is aural pleasure.




When designing SHOCKWAFE, we only thought of you.

The end result is a stellar-looking sound bar with everything you need, engineered to deliver the true audio experience.

Screen Shot 2015-12-30 at 4.05.09 AM.png


Ideally sized for exceptional projection of sound. Your large HDTV needs flawless sound too.


Complete audio and surround sound experience.

Screen Shot 2015-12-18 at 1.44.07 AM.png


Audio freedom. SHOCKWAFE comes with all connectivity options.

The remote that makes absolute sense.

Night-friendly and intelligent, its functionality will amaze you.


Basic TV learning capability


15 DSP surround modes


Night mode (Subwoofer 50% or OFF)


Full surround control

Shockwafe universal remote control

SHOCKWAFE comes with all connectivity options.


You can even stream music from your device wirelessly.



Left & Right: 4 X 2.5" Full Range drivers

Center: 2 X 2.5" Full Range drivers

Extreme Left & Right: 2 X 1.0" Surround Effects Tweeter on Each Side for Extra Acoustic Wideness


1 X 2.5" Full Range Drivers on Each Side


1 x 8" Speaker Driver (Ported Design)


Length: 45.5"


Channels: 7.1 Simulated

Sound Pressure Level: 104 dB

RMS Power: 150W

Sensitivity: 680mW

Frequency Response: 35Hz - 22kHz

Peak Power Handling: 400W





15 EQ Modes - Movie, Sports, TV, Music, Game, Night


HDMI In x 2 (4K Pass Through)

TV HDMI (ARC)  x 1

Analog Audio Input x 1

Optical Input x 1

Coaxial Input x 1

Bluetooth 3.0

USB X 1 (For Firmware Upgrade Only)


Dolby Audio

DTS Digital 5.1


Sound bar: 45.5 L X 3.3 W X 3.0 H Inch, 7.25 lb

Subwoofer: 7.9 L X 12.3 W X 16.7 H Inch, 15.5 lb

Satellite: 4.3 L X 6.7 W X  3.0 H Inch, 1.10 lb

Power Consumption: 80W (Sound Bar), 15W X 2 (Satellite Speakers), 60W (Subwoofer)

Voltage: 120V, 60Hz

Energy Star Certified



2 AAA Batteries

4 Velcro Strips

Wall Mounting - 8 Wall Screws, 4 Speaker Screws, 4 Brackets, 8 Wall Plugs

User Manual

Warranty Guide

Mounting Guide

Sound Bar


Left/Right Satellite Speakers

Left/Right Satellite Speaker Audio Cables (26.2' each)

Remote Control

HDMI Cable (4')

Optical Cable (4')

Aux-In (3.5mm) Cable (5.2')

Subwoofer Power Cable (4.7')






  1. Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby Laboratories.
  2. DTS, the Symbol, DTS-HD, and DTS or DTS-HD and the Symbol together are registered trademarks of DTS Inc., and all other DTS logos are trademarks of DTS, Inc.
  3. Bluetooth is a registered trademark of Bluetooth SIG. Inc.
  4. Shockwafe Pro is rated at 104dB. The Sound Pressure Level is measured using pink noise at 1 meter, C-weighted. The Total harmonic Distortion calculated as an electrical measurement of amplifier distortion.
  5. Wireless Subwoofer is rated -3dB @ 35Hz. Nakamichi uses the industry standard LINEAR X SYSTEMS, LMS electroacoustic analyzer. The bass frequency is measured using swept sine wave at 2 meters, parallel to the subwoofer driver’s technique.
