Compare
Nakamichi models
Quick Look
Hardware Specifications
1 x 45" Soundbar
6 x 2.75" Extended Range Twin-Cone Drivers
2 x 1" Silk Dome Surround Effects Tweeters
1 x 54" Soundbar
8 x 2.75" Punktkilde Full Range Drivers
(Left, Right, Inner and Outer Surround Channel)
2 x 3" Punktkilde Full Range Drivers
(Center Channel)
4 x 3" Punktkilde Full Range Up-firing Drivers
5 x 1" Punktkilde Tweeters
1 x 58" Main Unit
10 x 3" Drivers
4 x 3" Dual-Angled Up-firing Speakers
3 x 1.5" Air Motion Tweeters
2 x Wireless Subwoofers
1 x 10" Down-Firing Subwoofer (Each)
1 x 10" High-Output Subwoofer (Per Cabinet)
2 x Wireless Subwoofers
1 x 10" Punktkilde Subwoofer (Per Cabinet)
Up to 4 x Wireless Subwoofers
4 x 12" Carbon Fiber-Reinforced Aluminum Subwoofer with 12" Carbon Passive Radiator, or
2 x 12" Carbon Fiber-Reinforced Aluminum Subwoofer with 12" Carbon Passive Radiator, or
2 x Dual-Opposing 8" Subwoofers
4 x Side Surround Speakers (RCA Connection to Subwoofers)
1 x 3" Extended Range Twin-Cone Driver (Each)
1 x 1" Silk Dome Surround Effects Tweeter (Each)
2 x Bipolar Wireless Surround Speakers
2 x 3" Punktkilde Full Range Drivers
2 x 1" Punktkilde Tweeters
1 x 3" Punktkilde Up-firing Driver
2 x Omni-Motion Reference Surround Speakers
2 x 1.5" Air Motion Tweeters (Side and Rear Surround)
2 x 3.5" Drivers (Side and Rear Surround)
1 x 3" Rotatable Up-firing Driver
—
—
System Expandability
Wireless connection with up to 4 DRAGON subwoofer cabinets; modular expansions sold separately
Total Speaker Drivers
18
Total Speaker Drivers
31
Total Speaker Drivers
With 4 x 12" Subwoofers: 31
With 2 x 12" Subwoofers: 29
With 2 x Dual-Opposing 8" Subwoofers: 31
Audio Performance
Audio Channels
Up to 9.2.4
Audio Channels
11.2.6
Audio Channels
Up to 11.4.6 with 4 Wireless Subwoofer Cabinets
Loudness / Sound Pressure Level (SPL)
113 dB
Loudness / Sound Pressure Level (SPL)
120 dB
Loudness / Sound Pressure Level (SPL)
With 4 x 12" Subwoofers: 131 dB
With 2 x 12" Subwoofers: 127 dB
With 2 x Dual-Opposing 8" Subwoofers: 125 dB
Peak Power
Soundbar: 400 W
Subwoofer: 600 W (Each)
Surround Speaker (Left & Right): 150 W (Each)
Surround Speaker (Back Left & Right): 150 W (Each)
Peak Power
Soundbar: 1000 W
Subwoofer: 450 W (Each)
Surround Speaker: 200 W (Each)
Peak Power
Soundbar: 1500 W
Dual-Opposing 8" Subwoofer: 500 W (Each)
12" Subwoofer: 750 W (Each)
Surround Speaker: 250 W (Each)
Total Power
1300 W
Total Power
2300 W
Total Power
With 4 x 12" Subwoofers: 5000 W
With 2 x 12" Subwoofers: 3500 W
With 2 x Dual-Opposing 8" Subwoofers:
3000 W
Overall Frequency Response
20Hz - 20kHz
Overall Frequency Response
20Hz - 20kHz
Overall Frequency Response
With 4 or 2 x 12" Subwoofers: 19Hz - 40kHz
With 2 x Dual-Opposing 8" Subwoofers: 20Hz - 40kHz
Connectivity
Input
HDMI In
Optical In
Coaxial In
3.5mm Analog In
USB Type-A
Input
2 x HDMI 2.1 In
Optical In
Aux In
Input
3 x HDMI 2.1 In
Optical In
Aux In
Wireless Connectivity
Bluetooth 5.0 with aptX™ HD
Wireless Connectivity
Bluetooth 5.3
AirPlay 2
Wireless Connectivity
Bluetooth 5.0 with aptX™ HD
—
—
Audio Outputs
Optical Out
Aux Out
USB
Type-A (Firmware Upgrade Only)
USB
Type-A (Firmware Upgrade Only)
USB
Type-A (Firmware Upgrade Only)
Power Input
Soundbar: 100 - 240V, 50/60Hz
Subwoofer: 110 - 240V, 50/60Hz
Power Input
110 - 240V, 50/60Hz
Power Input
Main Unit: 100 - 240V, 50/60Hz
Surround Speakers: 110 - 240V, 50/60Hz
12" Subwoofer: 110 - 120V/220 - 240V, 50/60Hz
Dual-Opposing 8" Subwoofer: 110 - 240V, 50/60Hz
—
Wi-Fi
2.4 Ghz and 5 Ghz
—
HDMI
Number of Inputs & Outputs
3 Inputs / 1 Output (eARC)
Number of Inputs & Outputs
2 Inputs / 1 Output (eARC)
Number of Inputs & Outputs
3 Inputs / 1 Output (eARC)
Video Passthrough
up to 4K60Hz
Video Passthrough
up to 4K120Hz/8K60Hz
Video Passthrough
up to 4K120Hz/8K60Hz
Dolby Vision Pass-through
Yes
Dolby Vision Pass-through
Yes
Dolby Vision Pass-through
Yes
HDR Pass-through
Yes
HDR Pass-through
Yes
HDR Pass-through
Yes
—
Other Features Pass-through
VRR/ALLM/FRL
Other Features Pass-through
VRR/ALLM/FRL
HDMI CEC
Yes
HDMI CEC
Yes
HDMI CEC
Yes
4K Video Upscaling
No
4K Video Upscaling
No
4K Video Upscaling
Yes
Audio Format
Surround Formats
Dolby Atmos
DTS:X
Surround Formats
Dolby Atmos
DTS:X
Surround Formats
Dolby Atmos
DTS:X PRO
Codec Support
Dolby TrueHD
Dolby MAT
Dolby Digital Plus
Dolby Digital
DTS:X
DTS-HD Master Audio
DTS-HD High Resolution Audio
DTS Digital Surround
LPCM 7.1
LPCM 5.1
PCM 2.0
Codec Support
Dolby TrueHD
Dolby MAT
Dolby Digital Plus
Dolby Digital
DTS:X
DTS-HD Master Audio
DTS-HD High Resolution Audio
DTS Digital Surround
LPCM 7.1
LPCM 5.1
PCM 2.0
Codec Support
Dolby TrueHD
Dolby MAT
Dolby Digital Plus
Dolby Digital
DTS:X
DTS-HD Master Audio
DTS-HD High Resolution Audio
DTS Digital Surround
LPCM 7.1
LPCM 5.1
PCM 2.0
Audio Enhancement
Basic Room Size Calibration (3 predefined sizes)
Audio Enhancement
In-App Room Size Calibration
Audio Enhancement
Channel Volume Control
Quad Subwoofer Setup
Height Effects Setup
Audio Calibration
Display
Soundbar
5-Character Display
Soundbar
8-Character Display
Soundbar
2-Line Dot Matrix Display
Control
Remote Control
43-Key LED Backlit Infrared
Remote Control
43-Key LED Backlit Infrared
Remote Control
45-Key LED Backlit Bluetooth + Infrared
—
Smart App
Wireless Remote Control App Supports
iOS and Android
Smart App
Wireless Remote Control App Supports
iOS and Android
—
—
On-Screen Display
General Functions + Calibration
